Avenger는 원래 VPI 설립자인 Harry Weisfeld에 의해 12년 전부터 시작되었습니다. 설계 과정에서이 프로젝트는 다른 기존 VPI 테이블에 대한 과도한 수요로 인해 생산 중단되었습니다. Harry는 VPI Classic 턴테이블을 시작하고 완성하는데 주력했습니다. Prime의 개발 직후 행사 준비를 위해 창고를 청소하는 동안 Harry는 Avenger 설계도를 다시 발견하였고 이로인해 Avenger 설계는 다시 시작되게 되었습니다.
Avenger의 섀시는 레이어간에 댐핑 소재가있는 3개의 보세 아크릴 / 알루미늄 / 아크릴 레이어로 구성됩니다. 3개의 격리 강철 모서리 포스트, 3개의 볼트 및 거대한 베어링 어셈블리로 고정됩니다. 톤암을 고정하는 모서리 포스트는 조정 가능한 기계식 손잡이를 가지고있어 사용자가 테이블 높이를 높이거나 낮추는 기능을 쉽게 제공합니다. 또한 모서리 기둥은 원추형 턴테이블에 사용되는 가공 된 Delrin / 볼 베어링 격리베이스에있는 콘 안정기에 연결됩니다. 완전 조절 식 Armboard는 강성과 접지를 위해 5/5 “6061 알루미늄으로 만들어졌으며, 테이블은 모든 제조사 브랜드의 길이에 상관없이 최대 3개의 암을 장착 할 수 있습니다.?
300 RPM, 24 극, AC 동기 모터는 높은 토크와 함께 조용한 작동이 가능합니다. 모터는 별도의 알루미늄 및 강철 가공 어셈블리에 설치되며 20 파운드의 6061 알루미늄 플래터는 39 인치 원주에서 +/- .001 “의 정확도를 갖습니다.
The Table:
The Avenger chassis is three layers of bonded acrylic/aluminum/acrylic with damping material between layers.
3 stainless steel corner posts for both isolation and tonearm mounting and for mechanical grounding (up to 3 will fit).
The 300 RPM, 24 pole, AC synchronous motor is capable of high torque and quiet operation. The motor is installed in a separate aluminum and steel machined assembly
The Inverted bearing features a hardened stainless steel shaft, 60 Rockwell chrome hardened ball, spinning in a phosphor bronze bushing and sits on a PEEK thrust disc. The belt side load is placed at the center of the spinning bearing for zero teeter-totter effects
The 20 pound 6061 aluminum platter has an accuracy of +/- .001” in a 39” circumference
The motor pulley has an accuracy of +/- .0005” when leaving factory
JMW 12-3D with VPI pure copper wire
Specifications:
Wow and flutter: .03%
Speed Accuracy: .04%
Rumble: 82db down
Overall Dimensions 27″ x 23″ x 10″
Footprint is 23″ x 20″
68 lbs weight
Available Upgrades:
Periphery Ring clamp for the ultimate in record warp reduction
Analog Drive System (ADS) for the utmost accuracy in motor speed and fine speed adjustments.
Avenger Rim-Drive
Avenger Reference Magnetic Drive
Avenger Reference Feet
JMW-12-3DR
Additional JMW Tonearms
Additional Arm boards for third party arms
