Magnum Dynalab introduces another member to its line of Triode Tube FM ANALOG tuners, the MD 102T. Built with the same precision aligned R.F. section found in the highly capable MD 102, we have added Certified Amperex Bugle Boy 6922 tubes in the amplification stage of the audio section, providing audio realism and coloration for those customers with a special partiality for tube technology. With improving RF transmission equipment around the world, this Triode tuner allows you to experience the full emotion of the music as it was recorded, with the distinctive characteristics of the tube experience
A great FM tuner like the MD 102T allows you to evaluate a recording artist and hear the performance with all the transparency, imaging, and sound staging of the original recording without purchasing any software.
Why Analog?
Magnum Dynalab specializes in the research and development of ANALOG FM tuners as well as antennas. Many people question why we are one of the only companies that continue to build a truly ANALOG FM tuner and ANALOG remote control. The answer is very simple. The best SOUND can only be produced when the signal received by the tuner is tuned and maintained in the ANALOG domain. By maintaining the signal in the ANALOG domain the customer has infinite tuning across the FM band; this is achieved by the use of a knob instead of the pushbutton step function tuning offered by a digital tuner. Because of our design in the manufacturing cycle, the front end and the IF (intermediate frequency) amplifiers are precision aligned, which guarantees that all specifications are met all the time; this is not possible in a digitally tuned tuner, as they are dependent on the tolerances of the components.
By calibrating and aligning the IF (intermediate frequency) amplifiers we are optimizing SOUND, SENSITIVITY and SELECTIVITY.
We ask that you listen and compare any of our tuners against the competitors” similarly priced units and decide.
Features & Benefits
-
Tunable five stage ANALOG front end (the more stages, the better); provides station separation without affecting stereo separation; Magnum Dynalab”s in-house design
-
Certified Amperex Bugle Boy 6922 tubes in the amplification stage – proven leader among tube manufacturers to provide the highest listening experience from the tube topography
-
Balanced output — fully complimentary circuit insures a perfectly balanced signal
-
BW 1 – Ultra wide IF Band Width setting; this setting produces the best SOUND where adjacent channel interference is not a factor
-
BW 2 – Narrow IF Band Width setting; this setting produces the best sound where adjacent channel interference is a factor
-
Dual AGC (automatic gain control) stage — eliminates the need for a local and distant switch
-
Auto Blend RF Circuit — Automatically monitors and adjusts stereo separation to maximize “stereo quieting”, insuring the quietest stereo signal as possible. Greatly improving your listening quality.
-
Shielded torroidal transformer — reduces the noise floor of the tuner
-
Ultra linear capacitors in the power supply circuit — improve the frequency response
-
Precision voltage stabilizers in the power supply circuit — ensure precise tuning
-
Kimber Hyper-Pure copper wiring in the audio path — provides a clean, uncolored path for the signal
-
Burr Brown op amps with Black Gate capacitors — proven performance from industry leading suppliers with zero degradation over the long haul
-
Precision tunable matched IF (intermediate frequency) amplifiers — ensures consistent specifications for adjacent channel separation, alternate channel separation and low distortion
-
Dual antenna inputs — flexibility in choosing antennas
-
Defeatable mute — eliminates any interstation noise while tuning
-
Aluminum chassis — provides total shielding
-
Analog meters — easy to read center tune, multipath and signal strength measurements
-
WBT unbalanced (RCA) output connectors — low tolerance connector made of highly ductile “OFC” copper, 24 carat gold plated ensures a solid contact for interconnects
-
.093 thick printed circuit board – minimizes any residual vibration in the chassis
-
Gold plated NeutriK Balanced connectors — exact dimensions to ensure maximum conductivity
-
Fully shielded RF section-eliminates any interference from stray signals
-
20,000 uf. Filtration
[제품사양]
- 50 Db quieting : stereo 25.0 dBf
- capture ratio : > 1.5 dB
- image rejection : 110.0 dB
- signal to noise ratio : 80.0 dB
- alternate channel – wide : 70.0 dB
- alternate channel – narrow : 80.0 dB
- adjacent channel – wide : 3.0 dB
- adjacent channel – narrow : 35.0 dB
- THD – mono : 0.10%
- THD – stereo : 0.10%
- stereo separation : 50.0 dB
- AM suppression : 70.0 dB
- SCA rejection : 80.0 dB
- I.F. Rejection : 80.0 dB
- 19 Khz and 38 Khz component rejection : 75.0 dB
- audio frequency response (+/_ 1dB) : 15 Hz – 17 Khz
- balanced audio output (600 ohms) : 2.2 V
- line audio output (RCA) : 1.0 V
- line power : 20/220/230/240 Vac
- dimensions – (cm HWD) : 11.43 x 48.3 x 38.1
- weight (lbs./Kg) : 16/7.1
- power consumption (typ/max) : 50w/100w
